ROLAND EGX-20 DESKTOP ENGRAVER

ROLAND EGX-20 DESKTOP ENGRAVER

Roland EGX-20 desktop engraver combines user-friendly operation with robust capabilities, making it ideal for engraving awards, product serial numbers, office directories, and personalized items. It comes with a comprehensive suite of engraving software, ensuring you can start creating immediately. This machine is in excellent used condition, ready to meet your engraving needs.
Table size 220 (W) x 170 (D) mm (8-5/8 (W) x 6-11/16 (D) in.)
Table load weight Maximum 1 kg (2.2 1b.)
Carriage cutting range 203.2 (X) x 152.4 (Y) x 31.8 (Z) mm (8 (X) x 6 (Y) x 1-1/4 (Z) in.)
Carriage operating speed X and Y axes: 0.1 to 1 mm/s, 1 to 15 mm/s (0.0039 to 0.59 in./s)
Z axis: 0.1 to 1 mm/s, 1 to 6 mm/s (0.0039 to 0.23 in./s)
Cutting-depth control AST (Active Surface Tracking) system
Cuttable depth 3D Cutting mode: 0.05 to 7 mm (0.002 to 0.27 in.)
Engraving mode: 0.05 to 1 mm (0.002 to 0.039 in.)
Cuttable material Composition: Resin (acrylic, modeling wax, ABS, polyacetal, polycarbonate, styrene foam, etc.), wood, and plaster
Maximum thickness: 30 mm (1-1/8 in.)
Resolution 0.01 mm/step (0.00039 in./step)
Spindle motor 12 W (DC motor)
Spindle rotating speed 4,000 to 15,000 rpm
Overload detection feature Yes
Cutter diameter 3.175 mm (1/8 in.)
Interface Parallel (compliant with IEEE 1284)
Buttons and controls Movement button (joystick type), Power button, View button, Origin Set button, Speed control, and Spindle Speed control
Indicators Z-axis light, Power light, View light, and Origin Set light
Power supply Dedicated AC adapter
Input: AC 100 to 240 V ±10%, 50/60 Hz
Output: DC 19 V, 2.1 A
Power consumption Maximum during operation: 0.6 A at 100 V, 0.27 A at 240 V
Operating noise level Standby: Less than 45 dB (A)
No-load operation: Less than 70 dB (A) (according to ISO 7779)
External dimensions 515.2 (W) x 368.3 (D) x 270.6 (H) mm (20-5/16 (W) x 14-1/2 (D) x 10-5/8 (H) in.)
Machine weight 10.9 kg (24 1b.)
Operating environment Temperature: 5 to 40 ºC (41 to 104 ºF)
Relative humidity: 35 to 80% (no condensation)

Included items AC adapter/power cord, Parallel to USB cable, cutter, Roland Software Package and User’s Manuals on USB flash drive
